Today we will cover Earned Value Management (EVM).

These days, cost and schedule overruns are common among projects, and these costly plan deviations affect an organization’s credibility. If you are managing projects, you must be aware of the situation and know how detrimental and stressful overruns can be. If these deviations are not controlled, the project could be terminated.

You need a control mechanism to help you avoid this situation, and one such mechanism is Earned Value Management (EVM).

Earned Value Management (EVM)

Earned Value Management was developed in the 1960s when the US Air Force started using it in their programs. Since 2005, it has become a standard part of federal project risk management. These days EVM is a requirement for US government contracts.

According to the PMBOK Guide, EVM integrates the scope baseline with the cost and schedule baselines to form the performance measurement baseline.

Put simply, EVM is a performance measurement technique that integrates cost, schedule, and scope to provide you with project status, progress, and forecasting reports.

EVM uses Earned Value Analysis (EVA), a mathematical technique to determine project status, compute progress, and forecast results.

Fundamentals of Earned Value Management

Earned Value Management helps you find project status and measure project progress. To understand the fundamentals of Earned Value Management, please refer to the 32 guidelines defined under the EIA-748 standard.

These guidelines are broadly categorized under five principles, which are outlined below.

#1. Organization and Project Scope

The first section has five guidelines emphasizing work organization. You must define the Work Breakdown Structure to a level where you can connect it with the product deliverable; this will be the “what” part.

At the same time, you must have an Organization Breakdown Structure (OBS) that will define “who” will take care of the WBS element. This intersection point of WBS and OBS defines a control account.

 #2. Planning, Scheduling, and Budgeting

The next section has ten guidelines covering planning, scheduling, and budgeting requirements.

You should develop a resource-loaded schedule so you can determine your budget. This time phase and resource-loaded schedule is known as schedule baseline, and it is part of performance measurement baselines.

#3. Accounting Considerations

This section has six guidelines for capturing costs incurred (actual costs). You should record your actual cost in accordance with the planned work.

You should record the actual cost along with the earned value. Doing so at different times will affect the accuracy of readings.

#4. Analysis & Management Report

This section has six guidelines defining how to carry out analysis and reporting.

This is where you collect all project data and find variance and performance. If required, calculate a new budget (EAC) and do the forecasting. Note that all Earned Value Management calculations are performed on a control account level.

#5. Revision and Data Maintenance

This is the last section and has five baseline control guidelines.

This guideline provides details on managing change requests and updating the performance measurement baseline.

Elements of Earned Value Management

EVM has three essential elements:

  1. Planned Value (PV)
  2. Earned Value (EV)
  3. Actual Cost (AC)

You can call them primary data points as well.

Planned Value

Planned Value is the scheduled cost of work planned in a given time. It is also called Budgeted Cost of Work Scheduled (BCWS). The total Planned Value of the project is the Budget at Completion (BAC).

Earned Value

Earned Value is the value earned from the completed work at a given time.

Simply put, you can say that the Earned Value will show you the value of the completed work if the project was terminated today, which is also called Budgeted Cost of Work Performed (BCWP).

Actual Cost

The Actual Cost is the money spent to date. It is also called the Actual Cost of Work Performed (ACWP). This is the easiest element of EVM to identify since it just takes one look at the question.

Visit: Earned Value, Planned Value, and Actual Cost

Secondary Elements of Earned Value Management

You can calculate the following variances and performance indexes with the help of these four elements:

  • Schedule Variance
  • Cost Variance
  • Schedule Performance Index
  • Cost Performance Index
Variances

You have two variances in EVM: Schedule Variance and Cost Variance. These help you track project performance in dollars.

Schedule Variance

Schedule Variance is the difference between Earned Value and Planned Value. It tells you if you are ahead or behind schedule in terms of dollars.

Schedule Variance = Earned Value – Planned Value

SV = EV – PV

You are behind schedule if the Schedule Variance is negative, ahead of schedule if the Schedule Variance is positive, and on schedule if it is zero.

Cost Variance

Cost Variance is the difference between Earned Value and Actual Cost. It tells you whether you are under or over budget.

Cost Variance = Earned Value – Actual Cost

CV = EV – AC

You are over budget if the Cost Variance is negative, under budget if it is positive, and zero means you are right on target.

Visit: Schedule Variance and Cost Variance

Indexes

Like variances, indexes help you compare planned with actual progress, helping you understand how efficient your progress is. You have two indexes in EVM: Schedule Performance Index (SPI) and Cost Performance Index (CPI).

Schedule Performance Index

This is the ratio of Earned Value and Planned Value.

Schedule Performance Index = (Earned Value) / (Planned Value)

SPI = EV / PV

If the Schedule Performance Index is greater than one, you have completed more work than planned at that particular time, or you are ahead of schedule. If the Schedule Performance Index is less than one, you have completed less work than planned and are behind schedule. Lastly, if the Schedule Performance Index equals one, you have completed the work exactly as planned and are on schedule.

Cost Performance Index

This is the ratio between the Earned Value and Actual Cost.

Cost Performance Index = (Earned Value) / (Actual Cost)

CPI = EV / AC

You are earning less than what you are spending or are over budget if the CPI is less than one. If it is greater than one, you are earning more than you are spending and are under budget. If the CPI is one, the cost spent is equal to the cost earned and you are on budget.

Visit: Schedule Performance Index and Cost Performance Index

Variance and performance indices are examples of derived data points.

Earned Value Management in Forecasting

EVM helps you to forecast the following:

  • Estimate at Completion
  • Estimate to Complete
  • Variance at Completion
  • To Complete Performance Index

These tools serve as early warning signs for potential overruns.

Estimate at Completion

Estimate at Completion is the project’s total expected budget.

This is the price tag of the project at the end.

You can calculate the Estimate at Completion in four different scenarios.

Please refer to my blog post on Estimate at Completion for further details.

Estimate to Complete

Estimate to Complete lets you calculate the expected cost of completing the rest of the work.

You can calculate the Estimate to Complete in three different scenarios.

Please refer to my blog post on Estimate to Complete for more details.

Variance at Completion

Variance at Completion tells you how much you will be under or over budget when the project is complete. It is the difference between the Budget at Completion and the Estimate at Completion.

Variance at Completion = Budget at Completion – Estimate at Completion

VAC = BAC – EAC

You have spent more than planned if the Variance at Completion is negative. If the difference is positive, you have completed the project within the planned budget.

To Complete Performance Index

The To Complete Performance Index (TCPI) estimates the cost performance required by the project to meet the budgeted goal. Please note that the Cost Performance Index is the past performance, while the To Complete Performance Index is the future cost performance.

You can calculate the TCPI by dividing the remaining work by the remaining funds.

TCPI = (Remaining Work) / (Remaining Funds)

There are two cases in which you can calculate the TCPI:

Case I: under budget

TCPI = (BAC – EV) / (BAC – AC)

Case II: over budget

TCPI = (BAC – EV) / (EAC – AC)

So, you can see how EVM helps you analyze the project’s performance and forecasting.

Visit: To Complete Performance Index

Benefits of Earned Value Management

EVM offers immense benefits to project managers, sponsors, clients, and organizations.

Here are a few benefits of EVM:

  • Helps in better planning.
  • Integrates schedule and cost performance.
  • Provides greater control of project constraints.
  • Allows for improved planning processes and correlates time-phased budgets to the project tasks.
  • Shows the project’s status and progress.
  • Provides early notifications about deviations from the baseline.
  • Measures the project’s cost and schedule performance.
  • Tracks your project’s performance.
  • Gives clients a better understanding of the project’s progress.
  • Improves communication and project visibility, which helps prevent scope creep.
  • Helps you keep an eye on deviations from any performance measurement baselines.
  • Finds potential risk areas.
  • Increases clients’ confidence in your project’s success.
  • Provides better project visibility and increases accountability.

Earned Value Management vs Traditional Project Management

Project managers used to have two parameters: planned expenditures and actual expenditures in the past.

These two variables help the project manager compare planned spending with actual spending. However, this is not enough information to get the whole picture as the information is incomplete. It was not possible to understand the relationship between the completed work and the money spent.

Getting the cost performance of the project was not possible.

This is where EVM comes in. It helps project managers overcome the shortcomings of traditional project management methods.

Earned Value Management has several advantages over traditional project management, which focuses on planned and actual expenditures. EVM focuses on actual accomplishments and gives you an insight into the project.

EVM helps analyze the cost performance, schedule performance, cost variance, and schedule variance.

Earned Value Management Table

earned value managment evm table

Earned Value Management Chart

earned value managment evm chart

Summary

EVM helps analyze the project’s performance and predict the forecast. It provides you with quantitative data for decision-making. It is an excellent communication tool for project stakeholders because it helps them understand the project’s insights.

Many PMP aspirants find EVM concepts difficult because of the mathematical calculations. However, if you begin with the concepts, working with the calculations brings the abstract down to a tangible level.

I have written seven blog posts on EVM and project forecasting, explaining EVM concepts in clear language with concrete examples. This blog post is the first in a series of seven on Earned Value Management.
