Seven Basic Quality Tools

Today we will discuss the seven basic quality tools.

Quality is a commonly used term in all industries, including project management, operational management, business management, production, customer service, etc.

Quality gained prominence in Japan when Toyota moved up the ladder of growth by following quality standards. Over time, quality became synonymous with Toyota.

You can define quality in many ways; some definitions of quality by renowned professionals are as follows:

Joseph Juran defined quality as fitness for purpose.

Edward Deming defined it as meeting or exceeding customer expectations.

Crosby defined quality as conformance to requirements.

Put simply, you can say that quality is about:

  • Understanding customer requirements.
  • Designing to meet that need.
  • Developing processes that can create that design.
  • Controlling to ensure the output continually meets the design.

To understand quality, a survey was carried out involving 86 managers in the US. Below is their understanding of quality.

  • Perfection
  • Consistency
  • Eliminating waste
  • Speed of delivery
  • Compliance with policies and procedures
  • Providing a good, usable product
  • Doing it right the first time
  • Delighting or pleasing customers
  • Total customer service and satisfaction

Every industry has different parameters to measure quality. For example, in manufacturing, you can study quality using the following indices:

  • Performance
  • Features
  • Reliability
  • Conformance
  • Durability
  • Serviceability
  • Aesthetics
  • Perceived quality

For quality in the service industries, in hotels, airlines, hospitals, government agencies, etc., the parameters are:

  • Timeliness
  • Courtesy
  • Consistency
  • Accessibility and convenience
  • Accuracy
  • Responsiveness

In a nutshell, quality is about fitness for use and meeting or exceeding customer requirements.

Many professionals confuse quality with grade. Quality and grade are different; quality deals with conformance to requirements, while grade refers to features and functionalities. A high-grade watch can be a smartwatch with several features like heart rate monitors, pedometer, blood pressure monitors, and sleep monitors, etc.

However, if the smartwatch performs below expectations; for example, gives incorrect blood pressure readings, the sleep timer does not always work, etc, the product is said to have a high grade but low quality.

Likewise, if a cheap watch with no advanced features performs exceptionally well, you can say that it is a low-grade product but the quality is high.

In project management, quality is one of the six constraints; the others are schedule, budget, scope, risk, and resource.

Seven Basic Quality Tools

The seven basic quality tools are:

  1. Histogram
  2. Control Chart
  3. Pareto Diagram
  4. Fishbone Diagram
  5. Check Sheet
  6. Flowchart
  7. Scatter Diagram

#1. Histogram

A histogram diagram shows the frequency distribution. It shows the history or trend of a variable.

The variable can be defects, warranties, scraps, reworks, response time, etc. Deviation in a variable such as timeliness and accuracy can be represented graphically using a histogram.

The variations are also called observation or frequency, which is plotted on the vertical axis, while the parameter is on the horizontal axis. For example, crude sampling requires days of preparation, but if you want to see the distribution, you can use historical data in the form of a histogram.

Drawing Histograms is easy. Divide the entire range into equal intervals (bins). The frequency of the bin is plotted on the vertical axis and the interval on the horizontal.

histogram table
histogram
Uses of a Histogram
  • It provides a quick view of variation within a process.
  • It provides parameters with the highest frequency and maximum probability.
  • Helps to organize large data sets into a graph.
  • It is a good presentation tool.
Histogram Pros
  • It’s quite easy to draw.
  • It can be used to make a presentation to stakeholders.
  • It enhances quick decision-making.
  • It helps identify the level of deviation.
  • It shows the ranking of the cause of the defect.
Histogram Cons
  • It is difficult to compare two datasets.
  • It can only be used for continuous, not discrete data.

Now, let us move to the second tool of seven basic quality tools.

#2. Pareto Chart

A Pareto chart is a histogram that categorizes the observation and identifies the “vital few.” The word vital few becomes necessary as they have the maximum impact on the solution.

All projects have issues, and a project manager cannot spend time on solving all those issues. Hence, you must prioritize the vital few causes that are affecting your project most.

After prioritizing issues, you can see that solving 20% of root causes eliminates 80% of problems. This phenomenon is known as the Pareto rule.

A Pareto chart is a key tool in quality management and Six Sigma. It is a vertical bar graph that shows problems or opportunities in a prioritized order. The categories from the left of the graph include mutually exclusive items arranged in decreasing order.

The Pareto chart helps you segregate the problems, and then you can find their root causes. You can invest your effort in those causes and solve most of the problems.

To draw the Pareto chart, you collect the problems in your process, categorize them by their type, and draw a bar chart per their category. The most frequently occurring problems will be on the left and the least on the right side.

We will take a case study of spacecraft manufacturing for drawing a Pareto chart. Assuming regulatory standards have been followed, we will study defects in a printed circuit board of the spacecraft.

pareto chart table

Pareto chart for the distribution is shown below:

pareto chart graph
Benefits of a Pareto Chart
  • It helps you focus on solving the few causes generating the most problems.
  • It helps you visualize problems.
  • It is an excellent visual communication tool.
Pareto Chart Pros
  • Ideal for prioritizing discrete data.
  • Quite easy to draw.
  • Enhances quick decision-making.
  • Helps focus attention on critical issues.
Pareto Chart Cons
  • It does not show the root cause of a problem.
  • The Pareto principle is a rule of thumb and does not apply to all situations.
  • It shows the frequency, not the severity.

Read Pareto Chart in detail.

Now, we will discuss the third basic quality tool.

#3. Root Cause Analysis

This is also called the Ishikawa diagram, named after the Japanese Organizational Theorist, Kaoru Ishikawa. It is a visual tool used to brainstorm the likely causes for an issue. A root cause analysis diagram is shown below:

root cause analysis

In the manufacturing industry, the causes are classified into the 5M’s: Man, Material, Machine, Method, and Measurement.

Man: Are the personnel trained, are they motivated, are they skilled, experienced, periodically appraised/tested, is the training adequate, is it fit for purpose or just leisure in exercise, who facilitates the training, what is the track record of the facilitator, etc.

Material: Are the input materials in good condition, can they be readily sourced, what is the grade of material, are training kits and operating tools available, etc.

Machine: What type of machine are we using, is it reliable, do we have in-house repairing or do we need to outsource it, how good is its performance, etc.

Method: Is it a standard method or discretionary?

Measurement: Is the instrument calibrated, sensitive, precise? Is the outcome approximated? What is the tolerance error? How about recording? Is it properly done?

It is always a brainstorming session where ideas are introduced in the diagram until virtually everything contributing to the process is figured out. The next question then is, what could go wrong with this branch/component represented by a bone-arrow? What can be done in advance? Can it be replaced with a better approach? It is an idea-generating process, and all ideas are encouraged, as seemingly ‘crazy’ ideas may be the cardinal ones to help salvage a process. Such an idea ordinarily might have been overlooked.

There can be several subdivisions as more ideas continue to flow. It is the facilitator’s duty not to judge but first write the branch representing the idea.

To facilitate a fish-bone diagram brainstorming session, you should have soft skills which help in openness, a desire to get the truth, improve your relationship with others, and an ability to accept different ideas, etc.

As these questions are generated, you must objectively scrutinize them and check for areas of weaknesses. Root cause analyses mean you want to solve the problem right from the very root. If one branch is not sufficient, you can go for further subdivisions.

Root Cause Analysis Pros
  • Creative thinking and ideas are involved in its development
  • Useful for both forward (quality planning) and backward (quality control) studies
  • The most useful tool for identifying the cause of a problem
  • Opens opportunity for improvement
Root Cause Analysis Cons
  • It can become counterproductive if not well coordinated or facilitated
  • It only addresses one problem per time; therefore you may need several brainstorming sessions for multiple problems

Read Root Cause Analysis in detail.

Now we will move onto the fourth of the seven basic quality tools.

#4. Check Sheet

A check sheet is also known as a checklist. This is a data collection sheet that facilitates data interpretation. Since it captures quantitative data in the form of attribute data, it is also known as a tally sheet.

The differences between attribute data and variable data are:

checksheet table 1

The Check Sheet helps facilitate the data collection for further analysis. Consider the table below showing an inspection of a production line of a bottling company. The number or frequency of each defect is represented in the tally of slashes.

checksheet table 2
Check Sheet Pros
  • Helps to organize data gathering
  • The output can be used for a Pareto chart or a histogram
  • Facilitates interpretation of data
  • Can spur more ideas
Check Sheet Cons
  • Doesn’t find out the root cause of an identified defect.
  • Depends on the Pareto chart or histogram for data presentation.

#5. Control Chart

control chart

A control chart is a graphical tool that helps you find out if the process is in control.

Changes occur in every process, but it becomes a cause of concern when they cross the set limits and the process is out of control.

A control chart has two limits: control limits and specification limits.

Control limits are of two types:

Upper control limit (UCL): This is the maximum limit, and when the variable crosses it, you will initiate an investigation.

Lower control limit (LCL): This is the minimum point, and when the variable crosses it, you will initiate an investigation.

The project manager set control limits. Like control limits, specification limits are also of two types: upper and lower specification limits. The customer defines specification limits.

When the variable is beyond the specification limit in either direction, you can say that the product is defective and must find the defect’s cause.

Control limits are always stricter than the customer’s specification limits. Hence you can say that specification limits are always outside UCL and LCL.

Upper and lower control limits are based on standard statistical calculations used to establish the natural capability of a process. The quality team has to set the range between the upper and lower control limits. Usually, the limit is set to +/- 3? (3-sigma) quality standard.

Note that

1 Sigma = 68.26%

2 Sigma = 95.46%

3 Sigma = 99.73%

6 Sigma = 99.99%

A sigma represents the quality standard. 6-sigma is the highest quality standard and has been adopted by companies such as Motorola, Bank of America, General Electric, Airlines, JP Morgan Chase., to reduce waste and improve customer satisfaction and efficiency.

The Rule of Seven: When seven data points are observed on one side of the mean, there is cause for an investigation, as the process may be out of control. This is shown in the control chart below.

A cause can be a special cause or a common cause. A special cause is a usual occurrence and requires investigation, whereas a common cause is the normal change and is most likely to be within the tolerable limit.

A rule of seven is an example of a special cause.

Control Chart Pros
  • Useful for monitoring a process
  • Can show the real-time behavior of a process
  • Saves the cost of rework and system failure
  • It can be programmed and automated
  • Helps to meet customer specifications
Control Chart Cons
  • Does not display the root cause(s) of a deviation
  • Requires a level of technical expertise for use
  • Tendency to mistake common cause for a special cause and vice versa

Read more on Control Charts.

#6. Scatter Diagram

A Scatter Diagram shows you the relationship between two variables. The first variable is independent, while the other is the dependent variable.

A scatter diagram helps you study the correlation between two variables. For example, suppose the number of errors in a product batch could be related to the number of hours of overtime by personnel. In that case, the number of errors is the dependent variable, while the overtime hour is the independent variable.

The independent variable is plotted on the x-axis, while the dependent variable is on the y-axis.

scatter diagram table 1
scatter diagram

The line shown in the above image is known as the line of best fit. The line is drawn so that most data points crowd around it.

scatter diagram table 2
Scatter Diagram Pros
  • It helps to establish the relationship between variables
  • Can help in input vs. output simulations
  • Useful for the cause-and-effect study
Scatter Diagram Cons
  • Requires accurate and adequate data

Now we come to the last of the seven basic quality tools.

#7. Flow Charts

Flow Charts show the various steps to help quality managers find bottlenecks and improve the process flow performance.

The shapes used to draw flow charts are as follows:

flow chart shape table

A typical flow chart for getting PMP certification is shown below.

flow chart example

Once the flow chart is completed, you can review it to identify areas for improvement. This is where de-bottlenecking comes in. Standard Operating procedures most times require a flow chart to enable operators to understand the process flow.

It is applicable in computer programming and debugging of errors in a program.

Flow Chart Pros
  • Can help in process improvements
  • Useful for de-bottlenecking a process
  • Useful during a quality audit
  • Helps in problem-solving
  • It can help discover and therefore prevent a potential problem
  • It can be used to study the value chain of an entire process, e.g., SIPOC(Supplier, Input, Process, Output, Consumer) study
  • Pictorial and effective for presentation
Flow Chart Cons
  • It does not uncover underlying root causes
  • It needs to be updated after process review

Summary

Regardless of your industry or profession, I am sure that you must have used many of the above seven basic quality tools. These tools are helpful in different sections of your organization, and a better understanding of these quality tools will help you manage your processes better.

I hope this post on seven basic quality tools was useful to you.

Please share your experience in using these tools in your organization through the comments section.
